Hydrogen H2 Gas

Hydrogen H2 Gas

CAS No.: 1333-74-0
EINECS No.: 215-605-7
UN No.: UN1049
Dot Class: 2.1
Purity: 99.999%-99.9999%
Standard Packaging: 40L, 47L, 50L Cylinder
Molecular Weight: 201.588g/mol
Density: 0.089g/L
Chemical Property: Flammable Gas
Grade Standard: Industrial Grade, Medical Grade, Electronic Grade

Description:
Hydrogen is a single substance formed by hydrogen element, with chemical formula H2 and molecular weight of 2.01588. Under normal temperature and pressure, hydrogen is a colorless, tasteless, odorless, non-toxic, highly flammable and insoluble gas in water. The density of hydrogen is 0.089g/L (101.325kpa, 0°C), which is about 1/14 of air, and is the lowest density gas known.

Typical Application:
‌Energy Field‌
Hydrogen fuel cells efficiently convert chemical energy into electricity, offering clean, quiet operation. Widely used in transport and power generation, they enable zero-emission vehicles with long ranges, marking a key future automotive development.
Chip Manufacturing‌
During the chip manufacturing process, hydrogen is used as a reducing agent and protective gas. Hydrogen has important applications in chemical vapor deposition (CVD), annealing process, etching process, cleaning process, passivation process and hydrogen atom injection.
‌Petrochemical Industry‌
Hydrogen is used for hydrogenation treatment in the process of oil refining, which can remove impurities such as sulfur, nitrogen, and oxygen in oil and improve the quality of oil products.
‌Metallurgical Industry‌
Hydrogen can be used as a reducing agent to reduce metal oxides and extract metals. For example, in the smelting process of metals such as tungsten and molybdenum, hydrogen can reduce their oxides to metal elements.
‌Electronic Industry‌
In semiconductor manufacturing, hydrogen can reduce silicon oxides to silicon elements, improving the performance and reliability of devices.

Product Content:



Specification 99.999% 99.995%
Oxygen ≤1.0 ppmv ≤0.05 ppmv
Nitrogen ≤5.0  ppmv ≤0.2  ppmv
Carbon Dioxide ≤1.0 ppmv ≤0.02 ppmv
Carbon Monoxide ≤1.0 ppmv ≤0.02 ppmv
Methane ≤1.0 ppmv ≤0.01 ppmv
Water ≤3.0 ppmv ≤0.5 ppmv



Packaging & Shipping:



Product Hydrogen H2
Package Size 40Ltr Cylinder 47Ltr Cylinder 50Ltr Cylinder
Filling Content/Cyl 5 CBM 6 CBM 10 CBM
QTY Loaded in 20’Container 240 Cyls 200 Cyls 200 Cyls
Total Volume 1200 CBM 1200 CBM 2000 CBM
Cylinder Tare Weight 50 Kgs 52 Kgs 55 Kgs
Valve QF-30A
